iX4 Series
Product Categories
Product Tags (multiple selection)

iX4-200 Pro

product description
• For high volume printing.
• Printing speed up to 6 inches/sec.
Tags :
  • Printer-Printing-width-4"
  • Printer-Direct-thermal
Compare Inquire
  • With new mechanical design, iX4 Pro series supports a large 8.26 inch outer diameter label roll and up to 450 meter ribbon capacity. Featuring 8 ips print speed, even print with the highest speed, it can still maintain the perfect print quality. The iX4 pro series has built-in Ethernet, Dual USB hosts, USB device, RS-232, and it can be expanded with Wi-Fi, GPIO card.

    cp-2140ex_05
  •   Printing Method Direct Thermal & Thermal Transfer
      Printing Resolution 203 dpi(8 dots/mm)
      Printing Speed Max. 6 ips
      Printing Length Max. 100”(2540mm)
      Printing Width Max. 4.13”(105 mm)
      Memory 128MB DRAM, 128MB Flash ROM (USB storage up to 32GB)
      CPU Type 32 bit RISC microprocessor
      Sensors Reflective sensor x 1 (Movable) & Transmissive sensor x 1(Movable)
      Operation Interface LED indicator x 3, Button x 3
      Communication Interface USB device, RS-232
      Fonts Internal character sets standard, 5 alpha-numeric fonts from 0.049”H ~ 0.23” H (1.25mm ~ 6.0mm) Internal fonts are expandable up to 24x24 4 direction 0 ~ 270 rotation Soft fonts are downloadable, GB 18030 Standard (Chinese coded character set) support. Ability to print any Windows True Type font easily. Support scalable font
      Wireless Security N/A
      1D Barcodes PPLA: Code 39、UPC-A、UPC-E、Code 128 subset A/B/C、EAN-13、EAN-8、HBIC、Codabar、Plessey、UPC2、UPC5、Code 93、Postnet、
    UCC/EAN-128、,UCC/EAN-128 K-MART、 UCC/EAN-128 Random weight、Telepen、FIM、Interleaved 2 of 5 (Standard/with modulo 10 checksum/
    with human readable check digit/ with modulo 10 checksum & shipping bearer bars) 、GS1 Data bar (RSS)
    PPLB: Code 39、 UPC-A、 UPC-E、 Matrix 2 of 5、 UPC-Interleaved 2 of 5、Code 39 with check sum digit 、Code 93、EAN-13、EAN-8 (Standard, 2
    /5digit add-on) 、Codabar、Postnet、Code128 subset A/B/C、Code 128 UCC (shipping container code) 、Code 128 auto、UCC/EAN code 128
    (GS1-128) 、 Interleave 2 of 5、Interleaved 2 of 5 with check sum、Interleaved 2 of 5 with human readable check digit、German Postcode、Matrix 2 of
    5、 UPC Interleaved 2 of 5、 EAN-13 2/5 digit add-on、 UPCA 2/5 digit add-on、UPCE 2/5 digit add-on、GS1 Data bar (RSS)
    PPLZ: Code39、 UPC-A、 UPC-E、 Postnet、 Code128 subset A/B/C、Interleave 2 of 5、Interleaved 2 of 5 with check sum、Interleaved 2 of 5 with
    human readable check digit、Code 93、Code 39 with check sum digit、MSI、EAN-8、Codabar、Code 11、EAN-13、Plessey、GS1 Data bar (RSS) 、
    Industrial 2 of 5、 Standard 2 of 5、 Logmars
      2D Barcodes QR Code, PDF417 (includingMicroPDF), DataMatrix (ECC200), GS1 DataMatrix, MaxiCode
      Graphics PPLA: PCX, BMP, IMG, HEX,GDI PPLB: PCX, BMP, Binary raster, GDI PPLZ: GRF, Hex, GDI
      Emulation PPLA, PPLB, PPLZ, Auto
      Software-label Editing BarTender® from Seagull Scientific Argobar Pro support ODBC Database Connection: Excel, CSV, MS Access, MS SQL, Oracle MySQL, dBASE (*.dbf)
      Software-utility BarTender, ArgoxBar Pro, Printer Tool, Font Utility, iLabelPrint+
      Driver tools Windows Driver for Vista/Win7/Win8/Win10, LINUX Driver, macOS Driver, Raspberry Pi Driver
      Media Type Roll-feed, die-cut, continuous, fan-fold, black mark, tags, ticket in thermal paper or plain paper
      Media Max. width:4.48”(114mm). Min. width: 1” (25.4 mm). Thickness: 0.0025”~0.01” (0.0635mm~0.254mm) 8.26”(210mm)OD on a 3”(76mm) ID core. 7”(177.8mm) OD on a 1.5”(38mm) ID core
      Ribbon Max. width:4.4”(112mm). Min. width: 1” (25.4 mm). Length: 450m Wax, Max OD 3.2” (81.3mm). Core size ID 1”(25.4mm). Wax, Wax/Resin, Resin (Ribbon wound ink-side out or ink-side in: auto-detect)
      Drop Resistance N/A
      Printer Dimensions W 257 mm x H 263 mm x D 432 mm
      Printer Weight 13 kgs
      Power Source Internal Universal Switching Power supply. Input voltage: 100~240V, 50~60Hz
      Battery N/A
      Operation Environment Operation Temperature: 40°F~104°F (4°C~40°C), 0% ~ 90% non-condensing Storage Temperature: -4°F~122°F (-20°C~50°C)
      Real Time Clock Standard
      Optional Items Guillotine cutter, Rotary cutter, Peeler, Rewinder kit, WLAN, GPIO, External rewinder
      Agency Listing CE, CB, cULus, FCC, ICES, RoHS, BSMI
      Attention *Argox reserves the right to enhance and modify the specification without prior notice. Please check Argox sales representative for most updated specifications.

    • ArgoBar Pro V2.16

      Barcode editing software
      Support Windows Vista, Windows 7, Windows 8.1, Windows 10 (32-bit or 64-bit) Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2 (32-bit or 64-bit). ​
      Support languages: English, Simplified Chinese, Traditional Chinese Argobar Pro support ODBC Database Connection: Excel, CSV, MS Access, MS SQL, Oracle MySQL, dBASE (*.dbf)

      Download

    • BarTender 2022 R6

      Barcode editing software
      Support Windows11, Windows 10, Windows Server 2022, Server 2019, Server2016

      Download

    • BarTender 2016 R7

      Barcode editing software
      Support Windows11, Windows 10, Windows 8 and 8.1, Windows 7, Windows Vista, Windows Server 2022, Server 2019, Server2016, Server2012 R2, Server2012, Server 2008 R2, Server 2008

      Download

    • Printer Tool V1.1.1

      Printer setup software
      Supports Windows XP or later, and requires .Net Framework 3.5

      Download

    • Font Utility V3.04

      Font tool
      This tool software can use true type font (TTF) and printer fonts.
      Supports Windows XP or later versions

      Download

    • Printer Utility V4.37

      For use with additional printer settings.
      Supports Windows XP or later versions

      Download

    • Argox SDK V1.4.0

      Supports Java and C# programming languages
      Supports Windows/Android/Linux operating platforms (different programming languages ​​have different support ranges, please refer to the readme.html in the SDK for details)
      Supports PPLB, PPLZ emulation.

      Download

    • iLabelPrint+ V2.3.3 Google Play

      iLabelPrint+ is a label design and printing application for mobile devices. We can use this application to easily design practical or professional labels, and output them to label paper with the connected ARGOX label printer. Support Blurtooth, LAN, WiFi, USB OTG connection on Android v8.0 and above.

      Download

    • iLabelPrint+ V2.3.3 App Store

      iLabelPrint+ is a label design and printing application for mobile devices. We can use this application to easily design practical or professional labels, and output them to label paper with the connected ARGOX label printer. Support Blurtooth, LAN, WiFi connection on iOS 13 and above.

      Download
